stainless steel security window screen

FOB Reference Price:Get Latest Price
US $30-80 / Square Meters | 100 Square Meter/Square Meters (Min. Order)
Material:
304 316
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
MS
Model Number:
MS-01
Screen Netting Material:
Stainless Steel
Packing:
pvc bag,waterproof paper,pallets
Materials:
304,316
Our advantage 2:
Special inspector for quality stainless steel wire
Our advantage 3:
excellent export services
Our advantage 4:
export stainless steel mesh more than 10 years
Our advantage 5:
promptly quotation and best after sales services
Supply Ability
Supply Ability:
3000000 Square Meter/Square Meters per Day
Packaging & Delivery
Packaging Details
Packaging Details:Packing: in waterproof paper,PVC bag, wooden case.Custom packing available at request
Port
Xinggang
Lead Time :
Quantity(Square Meters) 1 - 1000 >1000
Est. Time(day) 5 To be negotiated

134

[ Material ]
1) Stainless steel 316

It is high tensile AISI316 stainless steel wire, tolerance(+/-0.01mm), tensile strength can reach to 1100-1150N. The holes are square

and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.
Characteristic:
Safe: Not easy to cut and break pass AS5039-2008
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty pass AS2331.3.1-2001
2) Stainless steel 304
It was produced by high tensile AISI304 stainless steel wire, tolerance(+/-0.01mm), tensile strength can reach to 1100-1150N.

The holes are square and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.
Characteristic:
Safe: Not easy to cut and break pass AS5039-2008
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty pass AS2331.3.1-2001

[ Surpasses the below standards ]
1) Knife Shear Test(AS5039-2008)
2) Anti-Jemmy Test(AS509-2008)
3) Pull Test(AS5039-2008)
4) Durable more than 10 years(AS2331.31-2001)
5) 3006 Hour Salt Spray Tests, 534 hours UV Test

[ Common Specification ]
8mesh*1.2mm, 9mesh*1.0mm, 10mesh*0.8mm, 10mesh*0.9mm, 11mesh*0.8mm, 11mesh*0.9mm, 12mesh*0.7mm,  12mesh*0.8mm, 12mesh*0.9mm, 14mesh*0.6mm, 14mesh*0.55mm, 14mesh*0.5mm, 18mesh*0.32mm
750mmx2000mm ,900mmx2000mm ,1000mmx2000mm ,1200mmx2000mm, 1500mm*2000mm
750mmx2400mm,  900mmx2400mm , 1000mmx2400mm, 1200mmx2400mm, 1500*2400mm
750mmx3000mm ,900mmx3000mm, 1000mmx3000mm  ,1200mmx3000mm, 1500*3000mm
750mmx3500mm ,900mmx3500mm , 1000mmx3500mm, 1200mmx3500mm, 1500*3500mm
